產品類型：英制圓錐滾子軸承
軸承型號:6580/6535
內徑(d):88.900mm
外徑(D):161.925mm
裝配高度(T):53.975mm
內圈高度(B):55.100mm
外圈高度(C):23.862mm
重量:4.703KG
硬度:59-62HRC
保持器：壓頂保持器
材質：軸承鋼，GCR15
外觀：精美，光亮，無劃痕，無磕碰傷
包裝：工業包裝或單個彩盒包裝
防銹：防銹質保二年
產品特點：高轉速 壽命長 高精度 低噪音
臨清市普菲軸承有限公司生產深溝球軸承和圓錐滾子軸承，英制圓錐滾子軸承，

產品全檢。內套和外套可以互換使用，按您要求來做包裝，如有需要，歡迎隨時詢價！

Bearing No.	Dimensions (mm)							Load Ratings (KN)		Mass
	d	D	B	C	T	r min	r1 min	C	Co	kg
1780/1729	25.400	56.896	19.837	15.875	19.368	0.8	1.3	43.1	40.0	0.230
1988/1922	28.575	57.150	19.355	15.875	19.845	3.5	1.5	46.0	41.8	0.220
2780/2720	36.487	76.200	25.654	19.050	23.812	1.5	3.3	67.0	85.0	0.513
3379/3320	34.925	80.167	30.931	23.812	29.370	3.5	3.3	95.0	112.0	0.700
3490/3420	38.100	79.375	29.771	23.812	29.370	3.5	3.3	93.0	114.0	0.669
3577/3525	41.275	87.312	30.886	30.162	30.162	3.5	0.5	96.0	120.0	0.814
3780/3720	50.800	93.264	30.302	23.812	30.162	3.5	3.3	102.0	134.0	0.858
3782/3720	34.925	85.725	30.162	23.812	30.162					0.890
3872/3820	34.925	85.725	30.162	23.812	30.162	3.5	3.3	105.0	132.0	0.890
3876/3820	38.100	85.725	30.162	23.812	30.162	3.5	3.3	105.0	132.0	0.848
3975/3920	50.800	112.712	30.048	23.812	30.162	3.5	3.3	83.0	116.0	1.510
3975/3926	50.800	112.712	30.048	26.988	33.338	3.5	3.3	112.0	165.0	1.590
3982/3920	63.500	112.712	30.048	23.812	30.162	3.5	3.3	119.0	174.0	1.200
3984/3920	66.675	112.712	30.048	23.812	30.162	3.5	3.3	119.0	174.0	1.120
6580/6535	88.900	161.925	55.100	23.862	53.975	3.5	3.3	310.0	460.0	4.703
